Excellent Dual-Camera Design
We provide OEM and ODM services, allowing you to choose from a variety of camera solutions including wide-angle, wide dynamic range (WDR), and low-light options. The inward-facing camera can be equipped with 940nm infrared to protect the human eye. Multiple optimized designs ensure a more stable and reliable camera for customers.
Equipped with network HD cameras, they provide better image quality, safer transmission, and easier maintenance.
Product Features:
Front Camera
1.1080P high resolution
2.Supports WDR function
3.Supports a wider angle
4.Supports ONVIF
5.Voltage: DC12V
6.Operating temperature: -30 to 70
Available Options:Economical version,WDR version,Low-light version
Interior Camera
1.1080P high resolution
2.Supports wide-angle video
3.Supports 940nm infrared light, infrared range of 3-5m
4.Supports audio collection
5.Supports ONVIF protocol
6.Voltage: DC12V
7.Operating temperature: -30 to 70
Specifications:
Front View Camera(FN-G7)
Image sensor | 1/2.9" 2MP progressive scan CMOS |
video codecs | H.264/H.265/Mjpeg(optional) |
encoding bitrate | 128Kbps-8Mbps |
maximum resolution | Main：1920*1080（25/30fps） |
network interface | 6-pin aviation connector |
camera angle | Max150° |
Image Mode | Normal |
Audio | Support |
audio codecs | G.711 |
GAMMA | 0.45 |
BLC | Auto |
AGC | Auto |
White Balance | Auto |
Electronic Shutter | 1/30’---1/50000’sceonds |
Mini illumination | 0.1lux |
dynamic range | 120db（WDR ON） |
SNR | 52Db |
basic protocol | TCP/IP,HTTP,FTP,DHCP,DNS,DDNS,RTP,RTSP, |
connection protocol | ONVIF/CGI |
Operating temperature | -30ºC---70ºC， RH95%MAX |
Storage temperature | -40ºC——80ºC，RH95%MAX |
Power Supply | 12V±10% |
1080P Internal View Vehicle IP Camera(FN-G3)
Image sensor | 1/2.9" 2MP progressive scan CMOS |
video codecs | H.264/H.265/Mjpeg(optional) |
encoding bitrate | 128Kbps-8Mbps |
maximum resolution | Main：1920*1080（25/30fps） |
network interface | 6-pin aviation connector |
camera angle | Max150° |
Image Mode | Normal |
Audio | Support |
audio codecs | G.711 |
GAMMA | 0.45 |
BLC | Auto |
AGC | Auto |
White Balance | Auto |
Electronic Shutter | 1/30’---1/50000’sceonds |
Mini illumination | 0lux |
nfrared night vision range | 3m-5m |
dynamic range | 85db（WDR ON） |
SNR | 52Db |
basic protocol | TCP/IP,HTTP,FTP,DHCP,DNS,DDNS,RTP,RTSP, |
connection protocol | ONVIF/CGI |
Operating temperature | -30ºC---70ºC， RH95%MAX |
Storage temperature | -40ºC——80ºC，RH95%MAX |
Power Supply | 12V±10% |
 |  |
